| Varenummer : | EEE-FT1E330AR |
|---|---|
| Producent / Mærke : | Panasonic |
| Beskrivelse : | CAP ALUM 33UF 20% 25V SMD |
| RoHs Status : | Blyfri / RoHS-kompatibel |
| Mængde Tilgængelig | 437064 pcs |
| Dataark | 1.EEE-FT1E330AR.pdf2.EEE-FT1E330AR.pdf3.EEE-FT1E330AR.pdf4.EEE-FT1E330AR.pdf5.EEE-FT1E330AR.pdf |
| Spændingsvurdering | 25V |
| Tolerance | ±20% |
| Overflade Mount Land Størrelse | 0.169" L x 0.169" W (4.30mm x 4.30mm) |
| Størrelse / Dimension | 0.157" Dia (4.00mm) |
| Serie | FT |
| Ripple Current @ Low Frequency | 104mA @ 120Hz |
| Ripple Current @ High Frequency | 160mA @ 100kHz |
| Vurderinger | AEC-Q200 |
| Polarisering | Polar |
| Emballage | Tape & Reel (TR) |
| Pakke / tilfælde | Radial, Can - SMD |
| Andre navne | EEEFT1E330AR PCE5004TR |
| Driftstemperatur | -55°C ~ 105°C |
| Monteringstype | Surface Mount |
| Fugtfølsomhedsniveau (MSL) | 1 (Unlimited) |
| Fabrikantens standard ledetid | 19 Weeks |
| Levetid @ Temp. | 2000 Hrs @ 105°C |
| Blyafstand | - |
| Blyfri Status / RoHS Status | Lead free / RoHS Compliant |
| Højde - Siddende (Max) | 0.240" (6.10mm) |
| ESR (Equivalent Series Resistance) | 850 mOhm @ 100kHz |
| Detaljeret beskrivelse | 33µF 25V Aluminum Electrolytic Capacitors Radial, Can - SMD 850 mOhm @ 100kHz 2000 Hrs @ 105°C |
| kapacitans | 33µF |
| Applikationer | Automotive |
